Number of hits 45
Pos.Item no.DescriptionExtra infoQty.
11078622Valve block EC204BPart of quick hitch1
Choose
2710702Seal washer GBR04 1/4"3
Choose
3710135adapter 138-04-29 ( compact 136-04-04 )2
Choose
4710703Seal washer GBR06 3/8"2
Choose
5710106adapter 136-06-062
Choose
O-ring 9,25x1,78 GREEN Viton 90 shore NG66710901O-ring 9,25x1,78 GREEN Viton 90 shore NG68
Choose
7730320cover plate NG61
Choose
8610401screw MC6S 5x16 12.9 untreated ISO47624
Choose
O-ring 7,65x1,78 GREEN Viton 90 shore NG49710960O-ring 7,65x1,78 GREEN Viton 90 shore NG412
Choose
101036082connection block EC204 ss01
Choose
11710151adapter 401-04-04 90°1
Choose
12710240Bulkhead adapter 1260-04-041
Choose
directional valve closed NG6 12V JT13730112directional valve closed NG6 12V JT(POS.9, 14, 15 incl.)1
Choose
Coil 12V NG6 JT on/off14730117Coil 12V NG6 JT on/off1
Choose
nut directional valve Argo Hytos15730135nut directional valve Argo Hytos1
Choose
screw MC6S 5x30 12.9 untreated ISO476216610403screw MC6S 5x30 12.9 untreated ISO4762Torque: 9,7Nm7
Choose
177000148directional valve closed NG4 12V DT(POS.9, 18, 19 incl.)2
Choose
187000897Coil 12V NG4 On/Off DT2
Choose
nut directional valve NG4191006785nut directional valve NG42
Choose
20610404screw MC6S 5x35 12.9 untreated ISO4762Torque: 9,7Nm8
Choose
211077744Tilt cylinder EC204BPart of top part1
Choose
227001940O-ring 6,75x1,78 NBR 70 shore4
Choose
231075504Valve block EC204B tilt cylinder1
Choose
24611039washer NL 6mmQTY: 8 part of make up10
Choose
25610591screw MC6S 6x35 12.9 untreated ISO47622
Choose
26611038washer NL 5mm4
Choose
27610405screw MC6S 5x40 12.9 untreated ISO4762Torque: 9,7Nm4
Choose
287001991Hose1
Choose
297001992Hose1
Choose
307001990Hose2
Choose
317002025HosePart of quick hitch assy.1
Choose
327002026HosePart of quick hitch assy.1
Choose
337002027Hose1
Choose
347002028Hose1
Choose
371034439Jumper DT tool lock valve SQ/QSC DC2/ss9-21
Choose
388002496Unit cable-ss9-2 EC204B1
Choose
ILME cover 8P/12P contact with jumper39810208ILME cover 8P/12P contact with jumper(Incl. with agg.cable)1
Choose
408002497Unit cable-ss9 joint EC204B1
Choose
411076341End lock protection plate EC204BS1
Choose
426000408Screw K6S 5x10 10.9 FZB ISO73804
Choose
431076425Cover plate EC204B TM-modulePart of make up1
Choose
441076007Protective cover valve block EC204B leftPart of make up1
Choose
451076360Protective cover valve block EC204B rightPart of make up1
Choose
466000242screw K6S 6x14 10.9 FZBPart of make up8
Choose
476000411Cage nut M6Part of make up2
Choose
Start > engcon för grävmaskiner > Tiltrotators > EC204B > Control system > ss9SQ
