Number of hits 94
PosItem no.DescriptionExtra infoQty.
61077005Bearing ring EC219 with steering(Only compatible with 8x25)1
71079941Axial washer with ear EC209/214/219Face grooves toward worm screw2
91062693Magnet Spacer Worm ScrewLoxeal 83-52. Torque: 20Nm1
247000790hosePart of quick hitch1
257000789hosePart of quick hitch1
267000724hosePart of quick hitch1
35611042washer NL 12mmQTY: 8 part of top part10
371078840Screw TX45 8x25 10,9 FZBTorque: 34Nm Tighten in cross pattern12
40711503Plug VSTIR18EDQTY: 2 for EC219S1
48612020screw MC6S 10x40 12.9 DacrometQTY: 4 for ECHF. Torque: 79Nm4
591030298Slip ring-ECHF-DTM/ PlugFor QS. See "Slip rings"1
651028391connection block under ECHF v.3Guide with spring pin from swivel1
686000155screw MC6S 12x55 12.9 ZFSHL ISO4762Part of top part. Torque: 136Nm8
71610556screw MC6S 20x90 12.9 untreated ISO4762Part of quick hitch. Torque: 649Nm12
91612201screw TX40 M8x30 FZB 10.+Torque: 34Nm. Used with 106192913
921016415End lock EC209/EC214/EC219Replaced by POS.15 from 2022-01 MACS: Replaces 1028628 from 16-101
931016414wear washer EC219Used until 2017-041
94610108screw M6S 6x12 8.8 FZBUsed until 2017-048
95710704Seal washer GBR08 1/2"Used until 2013-031
96710122adapter 135-06-08Used until 2013-031
1006000047Magnet Neodym35 8x5x3mm SVAB MACSLoctite 415. Harden 1 minute1
1011043698Inductive sensor M8 PNP NO 4mm - SVAB MACSDistance 3mm. Nut torque: 3Nm1
Start > engcon för grävmaskiner > Tiltrotators > EC219 > Rotator frame > Main components
