ss9IQ 'ECHF'

Pos

Artikel

Extra Info

Aantal in tekening

Prijs (excl. BTW)

Hose Tilt Long - EC214

Article no: 743001

Position45

Aantal in tekening4

Hose Tilt Long - EC214

Article no: 743001

Hose

Article no: 7000376

Position42

Aantal in tekening1

Hose

Article no: 7000376

Hose

Article no: 7000672

Position39

Aantal in tekening1

Hose

Article no: 7000672

Hose

Article no: 7000524

Position33

Aantal in tekening1

Hose

Article no: 7000524

Feed Right: Mount on left side Feed Left: Mount on right side

Hose

Article no: 7000032

Position47

Aantal in tekening1

Hose

Article no: 7000032

Connection block P ss9 ECHF/QSM 24V

Article no: 1027707

Position2

Aantal in tekening1

Connection block P ss9 ECHF/QSM 24V

Article no: 1027707

(Dump 24V & POS.3 included)

Valve-Double pressure relief EC206,209&ECHF

Article no: 730287

Position3

Aantal in tekening2

Valve-Double pressure relief EC206,209&ECHF

Article no: 730287

Connection block 2x 1/2" / 2x 3/8" NG6

Article no: 405670

Position12

Aantal in tekening1

Connection block 2x 1/2" / 2x 3/8" NG6

Article no: 405670

Hose feed - EC219 - valve block UNI top part

Article no: 742620

Position32

Aantal in tekening2

Hose feed - EC219 - valve block UNI top part

Article no: 742620

QTY: 1 for Feed Right/Left

Hose

Article no: 742335

Position37

Aantal in tekening1

Hose

Article no: 742335

Protective cover valve block EC214 - left

Article no: 1016548

Position48

Aantal in tekening1

Protective cover valve block EC214 - left

Article no: 1016548

Connection block P ss9 ECHF/QSM 12V

Article no: 1026282

Position1

Aantal in tekening1

Connection block P ss9 ECHF/QSM 12V

Article no: 1026282

(Dump 12V & POS.3 included)

Adapter 408-08-08 45°

Article no: 7000074

Position24

Aantal in tekening1

Adapter 408-08-08 45°

Article no: 7000074

Hose feed P - EC214 - valve block

Article no: 743010

Position30

Aantal in tekening1

Hose feed P - EC214 - valve block

Article no: 743010

Adapter 407-08-08 90°

Article no: 7000021

Position23

Aantal in tekening1

Adapter 407-08-08 90°

Article no: 7000021

Hose feed T - EC214 - valve block

Article no: 743007

Position31

Aantal in tekening1

Hose feed T - EC214 - valve block

Article no: 743007

Hose

Article no: 742653

Position36

Aantal in tekening1

Hose

Article no: 742653

QTY: 2 for option 2Bl.Feed

Hose

Article no: 742675

Position38

Aantal in tekening1

Hose

Article no: 742675

Protective cover valve block EC214 - right

Article no: 1016547

Position49

Aantal in tekening1

Protective cover valve block EC214 - right

Article no: 1016547

Hose

Article no: 7000377

Position44

Aantal in tekening1

Hose

Article no: 7000377

Protective cover valve block EC214 - right MACS

Article no: 1030154

Position50

Aantal in tekening1

Protective cover valve block EC214 - right MACS

Article no: 1030154

For MACS

Hose feed - EC214 - rotation all R/L

Article no: 743013

Position40

Aantal in tekening1

Hose feed - EC214 - rotation all R/L

Article no: 743013

Replaces "a" for Rot. Left Replaces "b" for Rot. Right

Adapter 234-12-08

Article no: 712219

Position21

Aantal in tekening1

Adapter 234-12-08

Article no: 712219

Adapter 402-04-04 45°

Article no: 7000104

Position46

Aantal in tekening1

Adapter 402-04-04 45°

Article no: 7000104

O-ring 15,54 x 2,62 NBR 70 shore

Article no: 712423

Position4

Aantal in tekening2

O-ring 15,54 x 2,62 NBR 70 shore

Article no: 712423

Screw MC6S 10x45 12.9 untreated ISO4762

Article no: 610589

Position6

Aantal in tekening4

Screw MC6S 10x45 12.9 untreated ISO4762

Article no: 610589

Adapter 401-06-08 90°

Article no: 710157

Position20

Aantal in tekening2

Adapter 401-06-08 90°

Article no: 710157

Adapter 488-08-08 90°

Article no: 712209

Position26

Aantal in tekening1

Adapter 488-08-08 90°

Article no: 712209

Screw MC6S 5x40 12.9 untreated ISO4762

Article no: 610405

Position28

Aantal in tekening4

Screw MC6S 5x40 12.9 untreated ISO4762

Article no: 610405

Washer NL10-DPE 10,7x16,6x2,7

Article no: 611041

Position5

Aantal in tekening8

Washer NL10-DPE 10,7x16,6x2,7

Article no: 611041

QTY: 4 part of make up

Adapter 136-12-12

Article no: 710126

Position17

Aantal in tekening2

Adapter 136-12-12

Article no: 710126

Adapter 135-04-06

Article no: 710118

Position11

Aantal in tekening4

Adapter 135-04-06

Article no: 710118

Plug VSTIR12ED 1/2"

Article no: 711500

Position15

Aantal in tekening4

Plug VSTIR12ED 1/2"

Article no: 711500

Adapter 135-08-12

Article no: 710109

Position25

Aantal in tekening1

Adapter 135-08-12

Article no: 710109

Adapter 136-08-08

Article no: 710108

Position22

Aantal in tekening1

Adapter 136-08-08

Article no: 710108

Seal washer GBR08 1/2"

Article no: 710704

Position18

Aantal in tekening3

Seal washer GBR08 1/2"

Article no: 710704

Seal washer GBR12 3/4"

Article no: 710706

Position16

Aantal in tekening2

Seal washer GBR12 3/4"

Article no: 710706

Adapter 135-06-08

Article no: 710122

Position19

Aantal in tekening2

Adapter 135-06-08

Article no: 710122

Plug VSTIR38ED 3/8"

Article no: 711504

Position13

Aantal in tekening4

Plug VSTIR38ED 3/8"

Article no: 711504

Screw M6S 10x20 8.8 FZB ISO4017

Article no: 610141

Position51

Aantal in tekening4

Screw M6S 10x20 8.8 FZB ISO4017

Article no: 610141

Adapter 401-06-06 90°

Article no: 710152

Position14

Aantal in tekening1

Adapter 401-06-06 90°

Article no: 710152

Seal washer GBR06 3/8"

Article no: 710703

Position10

Aantal in tekening4

Seal washer GBR06 3/8"

Article no: 710703

O-ring 9,25x1,78 FKM 90 shore Viton Green NG6

Article no: 710901

Position27

Aantal in tekening4

O-ring 9,25x1,78 FKM 90 shore Viton Green NG6

Article no: 710901
