HYD/Hydrema

Pos

Artikel

Extra Info

Aantal in tekening

Prijs (excl. BTW)

Adapter bulkhead 1260-06-32

Article no: 710242

Position15

Aantal in tekening2

Adapter bulkhead 1260-06-32

Article no: 710242

Screw M6S 8x16 8.8 FZB ISO4017

Article no: 610122

Position201

Aantal in tekening8

201

Screw M6S 8x16 8.8 FZB ISO4017

Article no: 610122

Screw cover M16

Article no: 611302

Position27

Aantal in tekening8

Screw cover M16

Article no: 611302

Part of make up

Adapter bulkhead extended 1260-06-43

Article no: 710262

Position16

Aantal in tekening2

Adapter bulkhead extended 1260-06-43

Article no: 710262

Endcover EC209 45x7 cylinder yoke

Article no: 710971

Position11

Aantal in tekening2

Endcover EC209 45x7 cylinder yoke

Article no: 710971

Overcenter adjustable-EC206/209/214/219W/226W/05B-15B

Article no: 730269

Position202

Aantal in tekening4

202

Overcenter adjustable-EC206/209/214/219W/226W/05B-15B

Article no: 730269

Nut bulkhead adapter 1270-06

Article no: 710252

Position17

Aantal in tekening2

Nut bulkhead adapter 1270-06

Article no: 710252

Adapter bulkhead 1260-04-04

Article no: 710240

Position21

Aantal in tekening2

Adapter bulkhead 1260-04-04

Article no: 710240

Screw K6S 8x25 10.9 untreated ISO 7380

Article no: 611814

Position26

Aantal in tekening1

Screw K6S 8x25 10.9 untreated ISO 7380

Article no: 611814

Adapter bulkhead extended 1260-04-40

Article no: 710261

Position22

Aantal in tekening2

Adapter bulkhead extended 1260-04-40

Article no: 710261

Tube clamp TIPP SMARTLOCK 11-15mm

Article no: 7000411

Position24

Aantal in tekening1

Tube clamp TIPP SMARTLOCK 11-15mm

Article no: 7000411

For one cable

Washer NL16-DPE 17,0x25,4x3,7

Article no: 611044

Position14

Aantal in tekening2

Washer NL16-DPE 17,0x25,4x3,7

Article no: 611044

Tube clamp TIPP SMARTLOCK 21-23mm

Article no: 7000413

Position25

Aantal in tekening1

Tube clamp TIPP SMARTLOCK 21-23mm

Article no: 7000413

For two or more cables

Yoke Bracket tilt cylinder EC209, EC214 cast grease-free

Article no: 1023212

Position7

Aantal in tekening4

Yoke Bracket tilt cylinder EC209, EC214 cast grease-free

Article no: 1023212

(POS.8-9 included)

Cable tie 7,8x360

Article no: 1021587

Position30

Aantal in tekening1

Cable tie 7,8x360

Article no: 1021587

Yoke Bracket tilt cylinder EC209

Article no: 1019740

Position6

Aantal in tekening2

Yoke Bracket tilt cylinder EC209

Article no: 1019740

(POS.8 included)

Screw MC6S 16x90 12.9 ZFSHL ISO4762

Article no: 6000151

Position10

Aantal in tekening4

Screw MC6S 16x90 12.9 ZFSHL ISO4762

Article no: 6000151

Torque: 333Nm

Nut bulkhead adapter 1270-04

Article no: 710250

Position23

Aantal in tekening2

Nut bulkhead adapter 1270-04

Article no: 710250

Washer NL1/2"-DPE 13,5x19,5x2,5

Article no: 611096

Position20

Aantal in tekening2

Washer NL1/2"-DPE 13,5x19,5x2,5

Article no: 611096

Hose protection Tiltcyl EC05B-15B, 206-214 overcenter

Article no: 1003774

Position200

Aantal in tekening2

200

Hose protection Tiltcyl EC05B-15B, 206-214 overcenter

Article no: 1003774

Cylindrical pin CPK Ø20x50 m6

Article no: 650211

Position9

Aantal in tekening4

Cylindrical pin CPK Ø20x50 m6

Article no: 650211

Bushing tilt EC02 WB802 30/34x30

Article no: 630003

Position5

Aantal in tekening2

Bushing tilt EC02 WB802 30/34x30

Article no: 630003

Bushing BWG-F 35/45/55/5x30

Article no: 631003

Position8

Aantal in tekening2

Bushing BWG-F 35/45/55/5x30

Article no: 631003
