ss0

Pos

Artikel

Extra Info

Aantal in tekening

Prijs (excl. BTW)

Adapter cable M12 8P-DTM 6S

Article no: 842148

Position77

Aantal in tekening1

Adapter cable M12 8P-DTM 6S

Article no: 842148

For Q-Safe

Hose

Article no: 7000608

Position76

Aantal in tekening1

Hose

Article no: 7000608

Feed Right & Feed Right+Left: Replace POS.74

Protective cover valve block EC209 right

Article no: 1016515

Position87

Aantal in tekening1

Protective cover valve block EC209 right

Article no: 1016515

Cable tie 4,8x371

Article no: 1021586

Position94

Aantal in tekening1

Cable tie 4,8x371

Article no: 1021586

Washer NL5-DPE 5,4x9,0x1,7

Article no: 611038

Position83

Aantal in tekening4

Washer NL5-DPE 5,4x9,0x1,7

Article no: 611038

Hose

Article no: 7000489

Position31

Aantal in tekening1

Hose

Article no: 7000489

Screw K6S 8x16H 10.9 FZB ISO7380

Article no: 611810

Position89

Aantal in tekening4

Screw K6S 8x16H 10.9 FZB ISO7380

Article no: 611810

Hose feed - Tilt A

Article no: 7001682

Position58

Aantal in tekening1

Hose feed - Tilt A

Article no: 7001682

Adapter 401-04-04 90°

Article no: 710151

Position16

Aantal in tekening2

Adapter 401-04-04 90°

Article no: 710151

Connection block 2x 1/2" / 2x 3/8" NG6

Article no: 405670

Position10

Aantal in tekening2

Connection block 2x 1/2" / 2x 3/8" NG6

Article no: 405670

QTY: 3 for ss0 with Grab

Hose feed - Tilt B

Article no: 7001683

Position59

Aantal in tekening1

Hose feed - Tilt B

Article no: 7001683

Hose

Article no: 7000406

Position60

Aantal in tekening2

Hose

Article no: 7000406

Hose

Article no: 7000335

Position39

Aantal in tekening1

Hose

Article no: 7000335

Screw M6S 10x20 8.8 FZB ISO4017

Article no: 610141

Position91

Aantal in tekening2

Screw M6S 10x20 8.8 FZB ISO4017

Article no: 610141

Hose

Article no: 7000609

Position66

Aantal in tekening1

Hose

Article no: 7000609

Rot. Left & Rot. Right+Left: Replace POS.64

Plug plastic - valve screw hole

Article no: 790156

Position92

Aantal in tekening12

Plug plastic - valve screw hole

Article no: 790156

Hose feed - EC209 - valve block UNI/HS08

Article no: 742855

Position47

Aantal in tekening2

Hose feed - EC209 - valve block UNI/HS08

Article no: 742855

(Same for Feed Right/Left)

Hose feed - EC209 - valve block

Article no: 742814

Position46

Aantal in tekening1

Hose feed - EC209 - valve block

Article no: 742814

For Right: a-side. For Left: b-side

Screw MC6S 5x30 12.9 untreated ISO4762

Article no: 610403

Position22

Aantal in tekening4

Screw MC6S 5x30 12.9 untreated ISO4762

Article no: 610403

Torque: 9,7Nm

Hose

Article no: 7000040

Position30

Aantal in tekening1

Hose

Article no: 7000040

Adapter 136-06-06

Article no: 710106

Position25

Aantal in tekening2

Adapter 136-06-06

Article no: 710106

Hose

Article no: 7000488

Position28

Aantal in tekening1

Hose

Article no: 7000488

Replaces "a" for Rot. Left Replaces "b" for Rot. Right

Screw MC6S 5x40 12.9 untreated ISO4762

Article no: 610405

Position20

Aantal in tekening8

Screw MC6S 5x40 12.9 untreated ISO4762

Article no: 610405

QTY: 12 for ss0 with Grab

Protective cover valve block EC209 left

Article no: 1016516

Position88

Aantal in tekening1

Protective cover valve block EC209 left

Article no: 1016516

Hose

Article no: 7000491

Position37

Aantal in tekening2

Hose

Article no: 7000491

QTY: 1 for Tilt Right/Left

Hose

Article no: 7000041

Position36

Aantal in tekening1

Hose

Article no: 7000041

Hose

Article no: 7000707

Position49

Aantal in tekening1

Hose

Article no: 7000707

Adapter 236-04-04

Article no: 1013885

Position18

Aantal in tekening2

Adapter 236-04-04

Article no: 1013885

Block-Overflow NG6

Article no: 1005844

Position11

Aantal in tekening2

Block-Overflow NG6

Article no: 1005844

QTY: 1 for ss0 with Grab

Hose

Article no: 7000650

Position75

Aantal in tekening1

Hose

Article no: 7000650

Feed Right: Replace POS.73

Adapter 135-04-08

Article no: 710120

Position17

Aantal in tekening4

Adapter 135-04-08

Article no: 710120

Hose

Article no: 7000708

Position52

Aantal in tekening1

Hose

Article no: 7000708

Connection block 2x 1/4" NG4

Article no: 1009586

Position13

Aantal in tekening1

Connection block 2x 1/4" NG4

Article no: 1009586

Block-Feed EC209 ss0

Article no: 1024278

Position1

Aantal in tekening1

Block-Feed EC209 ss0

Article no: 1024278

Hose

Article no: 7000605

Position34

Aantal in tekening1

Hose

Article no: 7000605

Hose

Article no: 7000008

Position68

Aantal in tekening1

Hose

Article no: 7000008

(same for Lock Right+Left)

Cable tie 7,8x360

Article no: 1021587

Position93

Aantal in tekening1

Cable tie 7,8x360

Article no: 1021587

Hose

Article no: 7000496

Position27

Aantal in tekening1

Hose

Article no: 7000496

Screw MC6S 5x12 12.9 untreated ISO4762

Article no: 6000077

Position84

Aantal in tekening6

Screw MC6S 5x12 12.9 untreated ISO4762

Article no: 6000077

Hose

Article no: 7000798

Position40

Aantal in tekening1

Hose

Article no: 7000798

Screw MC6S 5x35 12.9 untreated ISO4762

Article no: 610404

Position21

Aantal in tekening8

Screw MC6S 5x35 12.9 untreated ISO4762

Article no: 610404

QTY: 4 for ss0 with Grab

Hose

Article no: 7000490

Position32

Aantal in tekening1

Hose

Article no: 7000490

Hose

Article no: 7000797

Position35

Aantal in tekening1

Hose

Article no: 7000797

Hose

Article no: 7000600

Position63

Aantal in tekening1

Hose

Article no: 7000600

(same for Rot. Right+Left)

Hose

Article no: 7000500

Position33

Aantal in tekening1

Hose

Article no: 7000500

O-ring 15,3x2,4 NBR 70 shore EC209

Article no: 712402

Position2

Aantal in tekening2

O-ring 15,3x2,4 NBR 70 shore EC209

Article no: 712402

Hose

Article no: 7000002

Position69

Aantal in tekening1

Hose

Article no: 7000002

Lock Left & Lock Right+Left: Replace POS.67

Hose

Article no: 7000039

Position29

Aantal in tekening1

Hose

Article no: 7000039

Hose

Article no: 7000652

Position70

Aantal in tekening1

Hose

Article no: 7000652

Lock Left: Replace POS.68

Hose

Article no: 7000487

Position26

Aantal in tekening1

Hose

Article no: 7000487

Hose

Article no: 7000407

Position48

Aantal in tekening1

Hose

Article no: 7000407

Hose feed - EC209 - Top part QS45/50

Article no: 7000012

Position45

Aantal in tekening2

Hose feed - EC209 - Top part QS45/50

Article no: 7000012

QTY: 1 for Feed Right/Left

Deutsch DTM06-6S connector device

Article no: 8000053

Position78

Aantal in tekening1

Deutsch DTM06-6S connector device

Article no: 8000053

Adapter 135-06-08

Article no: 710122

Position15

Aantal in tekening2

Adapter 135-06-08

Article no: 710122

Hose Tilt Long

Article no: 7000791

Position7

Aantal in tekening4

Hose Tilt Long

Article no: 7000791

O-ring 7,65x1,78 FKM 90 shore Viton NG4

Article no: 710960

Position12

Aantal in tekening4

O-ring 7,65x1,78 FKM 90 shore Viton NG4

Article no: 710960

O-ring 9,25x1,78 FKM 90 shore Viton Green NG6

Article no: 710901

Position9

Aantal in tekening16

O-ring 9,25x1,78 FKM 90 shore Viton Green NG6

Article no: 710901

Seal washer GBR08 1/2"

Article no: 710704

Position14

Aantal in tekening6

Seal washer GBR08 1/2"

Article no: 710704

Banjo bolt 4451-04

Article no: 710271

Position6

Aantal in tekening4

Banjo bolt 4451-04

Article no: 710271

Washer NL10-DPE 10,7x16,6x2,7

Article no: 611041

Position90

Aantal in tekening6

Washer NL10-DPE 10,7x16,6x2,7

Article no: 611041

Seal washer GBR06 3/8"

Article no: 710703

Position24

Aantal in tekening2

Seal washer GBR06 3/8"

Article no: 710703

Plug VSTIR38ED 3/8"

Article no: 711504

Position19

Aantal in tekening4

Plug VSTIR38ED 3/8"

Article no: 711504

QTY depends on config. (4-8)

Seal washer GBR04 1/4"

Article no: 710702

Position5

Aantal in tekening8

Seal washer GBR04 1/4"

Article no: 710702

Mounting plate-ePS-Tilt sensor except Trimble-EC209

Article no: 1039019

Position82

Aantal in tekening1

Mounting plate-ePS-Tilt sensor except Trimble-EC209

Article no: 1039019

(Trimble directly on POS.81)

Attachment Tiltrotator module DC2 & ePS EC209

Article no: 1038301

Position81

Aantal in tekening1

Attachment Tiltrotator module DC2 & ePS EC209

Article no: 1038301

Washer NL8-DPE 8,7x13,5x2,7

Article no: 611040

Position3

Aantal in tekening8

Washer NL8-DPE 8,7x13,5x2,7

Article no: 611040

QTY: 4 part of make up

Protection sensor -ePS, SVAB MACS-V2-EC209,EC214,EC219

Article no: 1033565

Position80

Aantal in tekening1

Protection sensor -ePS, SVAB MACS-V2-EC209,EC214,EC219

Article no: 1033565

Resistor cable 120ohm M12 5S-M12 5S-3m

Article no: 8000824

Position86

Aantal in tekening1

Resistor cable 120ohm M12 5S-M12 5S-3m

Article no: 8000824

Extension cable 5-pole M12-FULL 0,75m Robo hose

Article no: 8000784

Position85

Aantal in tekening1

Extension cable 5-pole M12-FULL 0,75m Robo hose

Article no: 8000784

Cut cable protection: 130mm
