ss9IQ

Pos

Artikel

Extra Info

Aantal in tekening

Prijs (excl. BTW)

Directional valve closed NG6 12V JT

Article no: 730112

Position10

Aantal in tekening1

Directional valve closed NG6 12V JT

Article no: 730112

(POS.9 incl.)

Adapter cable M12 8P-DTM 6S

Article no: 842148

Position27

Aantal in tekening1

Adapter cable M12 8P-DTM 6S

Article no: 842148

Directional valve NG4 closed 12V JT

Article no: 730330

Position17

Aantal in tekening2

Directional valve NG4 closed 12V JT

Article no: 730330

(POS.14 incl.)

Screw K6S 8x16H 10.9 FZB ISO7380

Article no: 611810

Position33

Aantal in tekening4

Screw K6S 8x16H 10.9 FZB ISO7380

Article no: 611810

Part of make up

Unit cable ss9-2 DT EC206-EC233-3,5m

Article no: 8001823

Position25

Aantal in tekening1

Unit cable ss9-2 DT EC206-EC233-3,5m

Article no: 8001823

Screw MC6S 8x25 12.9 ZFSHL ISO4762

Article no: 6000143

Position8

Aantal in tekening2

Screw MC6S 8x25 12.9 ZFSHL ISO4762

Article no: 6000143

Adapter cable JT 2P-SQR 4S

Article no: 302971

Position19

Aantal in tekening1

Adapter cable JT 2P-SQR 4S

Article no: 302971

ILME cover21.21 with lever CKAX 03 CXA

Article no: 810208

Position26

Aantal in tekening1

ILME cover21.21 with lever CKAX 03 CXA

Article no: 810208

(Incl. with agg.cable)

Screw K6S 6x20 10.9 FZB ISO 7380

Article no: 6000339

Position30

Aantal in tekening2

Screw K6S 6x20 10.9 FZB ISO 7380

Article no: 6000339

Torque: 79Nm

Hose Tilt EC206B

Article no: 7001694

Position4

Aantal in tekening2

Hose Tilt EC206B

Article no: 7001694

Screw MC6S 5x30 12.9 untreated ISO4762

Article no: 610403

Position11

Aantal in tekening4

Screw MC6S 5x30 12.9 untreated ISO4762

Article no: 610403

Torque: 9,7Nm

End lock protection plate EC206BS

Article no: 1062673

Position29

Aantal in tekening1

End lock protection plate EC206BS

Article no: 1062673

Hose EC206B ss9 Rot A

Article no: 7001669

Position23

Aantal in tekening1

Hose EC206B ss9 Rot A

Article no: 7001669

Part of quick hitch assy.

Block feed EC206B

Article no: 1061758

Position6

Aantal in tekening1

Block feed EC206B

Article no: 1061758

Hose EC206B ss9 Rot B

Article no: 7001670

Position24

Aantal in tekening1

Hose EC206B ss9 Rot B

Article no: 7001670

Part of quick hitch assy.

Dumper block 12V JT NG6 EC206 - complete

Article no: 1026714

Position13

Aantal in tekening1

Dumper block 12V JT NG6 EC206 - complete

Article no: 1026714

(Dump valve incl.)

Adapter 136-08-08

Article no: 710108

Position21

Aantal in tekening2

Adapter 136-08-08

Article no: 710108

Hose feed - EC206B

Article no: 7001692

Position22

Aantal in tekening2

Hose feed - EC206B

Article no: 7001692

Screw MC6S 5x35 12.9 untreated ISO4762

Article no: 610404

Position18

Aantal in tekening8

Screw MC6S 5x35 12.9 untreated ISO4762

Article no: 610404

Torque: 9,7Nm

Protective cover valve block EC206B right

Article no: 1060973

Position31

Aantal in tekening1

Protective cover valve block EC206B right

Article no: 1060973

Part of make up

Protective cover valve block EC206B left

Article no: 1061668

Position32

Aantal in tekening1

Protective cover valve block EC206B left

Article no: 1061668

Part of make up

Directional valve NG4 IQS lock 12V DT ss9 Coil A

Article no: 1042045

Position15

Aantal in tekening1

Directional valve NG4 IQS lock 12V DT ss9 Coil A

Article no: 1042045

(POS.14 incl.)

Screw MC6S 5x50 12.9 untreated ISO4762

Article no: 610407

Position16

Aantal in tekening7

Screw MC6S 5x50 12.9 untreated ISO4762

Article no: 610407

Torque: 9,7Nm

O-ring 7,65x1,78 FKM 90 shore Viton NG4

Article no: 710960

Position14

Aantal in tekening12

O-ring 7,65x1,78 FKM 90 shore Viton NG4

Article no: 710960

O-ring 9,25x1,78 FKM 90 shore Viton Green NG6

Article no: 710901

Position9

Aantal in tekening4

O-ring 9,25x1,78 FKM 90 shore Viton Green NG6

Article no: 710901

Seal washer GBR08 1/2"

Article no: 710704

Position20

Aantal in tekening2

Seal washer GBR08 1/2"

Article no: 710704

O-ring 12,42x1,78 NBR 70 shore

Article no: 710973

Position5

Aantal in tekening2

O-ring 12,42x1,78 NBR 70 shore

Article no: 710973

Plug VSTIR12ED 1/2"

Article no: 711500

Position1

Aantal in tekening2

Plug VSTIR12ED 1/2"

Article no: 711500

Seal washer GBR04 1/4"

Article no: 710702

Position2

Aantal in tekening2

Seal washer GBR04 1/4"

Article no: 710702

Washer NL8-DPE 8,7x13,5x2,7

Article no: 611040

Position7

Aantal in tekening14

Washer NL8-DPE 8,7x13,5x2,7

Article no: 611040

QTY: 4 part of make up

O-ring 8,73x1,78 NBR 90 shore

Article no: 710959

Position12

Aantal in tekening4

O-ring 8,73x1,78 NBR 90 shore

Article no: 710959
