Main components 'From 2009-01'

Pos

Artikel

Extra Info

Aantal in tekening

Prijs (excl. BTW)

Worm wheel EC20 M20

Article no: 300863

Position9

Aantal in tekening1

Worm wheel EC20 M20

Article no: 300863

Shim tilt axle - EC20 - spring steel 61x95x0,5

Article no: 650501

Position38

Aantal in tekening1

Shim tilt axle - EC20 - spring steel 61x95x0,5

Article no: 650501

0,5 mm

Shim tilt axle - EC20 - spring steel 61x95x1

Article no: 650502

Position39

Aantal in tekening1

Shim tilt axle - EC20 - spring steel 61x95x1

Article no: 650502

1 mm

Protective cover valve block EC20

Article no: 300118

Position5

Aantal in tekening1

Protective cover valve block EC20

Article no: 300118

Bushing WB802 80/85x40

Article no: 630103

Position15

Aantal in tekening1

Bushing WB802 80/85x40

Article no: 630103

Rotator frame 20HD Yellow

Article no: 101277

Position4

Aantal in tekening1

Rotator frame 20HD Yellow

Article no: 101277

Shim centre ring - EC20 - 1,0mm

Article no: 201365

Position43

Aantal in tekening1

Shim centre ring - EC20 - 1,0mm

Article no: 201365

1,0 mm

Shim centre ring - EC20 - 0,8mm

Article no: 201405

Position44

Aantal in tekening1

Shim centre ring - EC20 - 0,8mm

Article no: 201405

0,8 mm

Shim centre ring - EC20 - 1,1mm

Article no: 201407

Position46

Aantal in tekening1

Shim centre ring - EC20 - 1,1mm

Article no: 201407

1,1 mm

Shim centre ring - EC20 - 0,7mm

Article no: 201793

Position47

Aantal in tekening1

Shim centre ring - EC20 - 0,7mm

Article no: 201793

0,6 mm

Shim centre ring - EC20 - 0,4mm

Article no: 202055

Position49

Aantal in tekening1

Shim centre ring - EC20 - 0,4mm

Article no: 202055

0,4 mm

Shim centre ring - EC20 - 0,5mm

Article no: 202056

Position50

Aantal in tekening1

Shim centre ring - EC20 - 0,5mm

Article no: 202056

0,5 mm

Centre ring - EC20 - should have shim, as of 05-01-01

Article no: 302807

Position7

Aantal in tekening1

Centre ring - EC20 - should have shim, as of 05-01-01

Article no: 302807

Replacing 300332 from 05-01-01 - mounted with shims

Worm screw EC20

Article no: 300030

Position14

Aantal in tekening1

Worm screw EC20

Article no: 300030

Axial washer EC10, EC20

Article no: 300031

Position13

Aantal in tekening2

Axial washer EC10, EC20

Article no: 300031

Support ring 80/100x3,5 Din 988

Article no: 650301

Position16

Aantal in tekening1

Support ring 80/100x3,5 Din 988

Article no: 650301

Wear washer EC20

Article no: 400310

Position18

Aantal in tekening1

Wear washer EC20

Article no: 400310

Shim worm screw - EC10, EC15, EC20 - 80/100x0,1

Article no: 650513

Position26

Aantal in tekening1

Shim worm screw - EC10, EC15, EC20 - 80/100x0,1

Article no: 650513

0,1 mm

Shim worm screw - EC10, EC15, EC20 - 80/100x0,2

Article no: 650514

Position27

Aantal in tekening1

Shim worm screw - EC10, EC15, EC20 - 80/100x0,2

Article no: 650514

0,2 mm

Shim worm screw - EC10, EC15, EC20 - 80/100x0,3

Article no: 650515

Position28

Aantal in tekening1

Shim worm screw - EC10, EC15, EC20 - 80/100x0,3

Article no: 650515

0,3 mm

O-ring 319,3x5,7 - Quick hitch EC10/EC219/EC226

Article no: 710908

Position8

Aantal in tekening1

O-ring 319,3x5,7 - Quick hitch EC10/EC219/EC226

Article no: 710908

Bushing WB802 45/50x50

Article no: 630102

Position25

Aantal in tekening1

Bushing WB802 45/50x50

Article no: 630102

Screw MC6S 12x16H 12.9 ZFSHL ISO4762

Article no: 610470

Position34

Aantal in tekening2

Screw MC6S 12x16H 12.9 ZFSHL ISO4762

Article no: 610470

12.9 Untreated ISO 4762 - Changed from 05-10-03

Motor cover EC20(&old EC30)

Article no: 100010

Position1

Aantal in tekening1

Motor cover EC20(&old EC30)

Article no: 100010

O-ring 10,77x2,62 NBR 70 shore

Article no: 710910

Position19

Aantal in tekening1

O-ring 10,77x2,62 NBR 70 shore

Article no: 710910

Cylindrical pin CPK Ø3x12 m6

Article no: 650201

Position17

Aantal in tekening2

Cylindrical pin CPK Ø3x12 m6

Article no: 650201

Feather key 10x8x50 C45 EC05B,EC15,EC20,EC214,EC219,EC226

Article no: 650102

Position21

Aantal in tekening4

Feather key 10x8x50 C45 EC05B,EC15,EC20,EC214,EC219,EC226

Article no: 650102

O-ring 419,3x5,7 Quick hitch EC20

Article no: 710909

Position24

Aantal in tekening1

O-ring 419,3x5,7 Quick hitch EC20

Article no: 710909

Screw MC6S 8x16H 12.9 ZFSHL ISO4762

Article no: 610432

Position35

Aantal in tekening2

Screw MC6S 8x16H 12.9 ZFSHL ISO4762

Article no: 610432

12.9 Untreated ISO 4762 - Changed from 05-10-03

Screw M6S 10x25 8.8 FZB ISO4017

Article no: 610142

Position6

Aantal in tekening4

Screw M6S 10x25 8.8 FZB ISO4017

Article no: 610142

Screw M6S 6x12 8.8 FZB ISO4017

Article no: 610108

Position20

Aantal in tekening8

Screw M6S 6x12 8.8 FZB ISO4017

Article no: 610108

Lubrication nipple 1/8 straight

Article no: 711403

Position11

Aantal in tekening14

Lubrication nipple 1/8 straight

Article no: 711403

R1/8" Straight

Washer BRB FZB 10,5x22x2 ISO7089

Article no: 611006

Position33

Aantal in tekening8

Washer BRB FZB 10,5x22x2 ISO7089

Article no: 611006

Screw M6S 10x20 8.8 FZB ISO4017

Article no: 610141

Position32

Aantal in tekening4

Screw M6S 10x20 8.8 FZB ISO4017

Article no: 610141

Cylinder axle EC20 hardened

Article no: 302853

Position36

Aantal in tekening2

Cylinder axle EC20 hardened

Article no: 302853

Replacing 300033 from 05-10-03

Bushing tilt EC20 WB802 60/65x60

Article no: 630301

Position10

Aantal in tekening2

Bushing tilt EC20 WB802 60/65x60

Article no: 630301

Tilt axle EC20 hardened

Article no: 302830

Position2

Aantal in tekening2

Tilt axle EC20 hardened

Article no: 302830

Replacing 300036 from 05-10-03

Screw MC6S 16x80 12.9 untreated ISO4762

Article no: 610528

Position31

Aantal in tekening10

Screw MC6S 16x80 12.9 untreated ISO4762

Article no: 610528
