ss5

Pos

Artikel

Extra Info

Aantal in tekening

Prijs (excl. BTW)

Hydraulic block(valve block) - rotation EC05B

Article no: 1010405

Position32

Aantal in tekening1

Hydraulic block(valve block) - rotation EC05B

Article no: 1010405

Directional valve NG4 lock 12V Flying leads

Article no: 730161

Position27

Aantal in tekening1

Directional valve NG4 lock 12V Flying leads

Article no: 730161

Directional valve NG4 tilt 12V Flying leads

Article no: 730145

Position25

Aantal in tekening1

Directional valve NG4 tilt 12V Flying leads

Article no: 730145

RPE3-043Y11/01200E8

Unit cable ss10 DT ILME 10P EC05B-3,4m

Article no: 1008632

Position37

Aantal in tekening1

Unit cable ss10 DT ILME 10P EC05B-3,4m

Article no: 1008632

Hydraulic block(motor) - rotation EC05B

Article no: 1010409

Position31

Aantal in tekening1

Hydraulic block(motor) - rotation EC05B

Article no: 1010409

Washer NL12-DPE 13,0x19,5x2,7

Article no: 611042

Position28

Aantal in tekening2

Washer NL12-DPE 13,0x19,5x2,7

Article no: 611042

Nut bulkhead adapter 1270-06

Article no: 710252

Position45

Aantal in tekening2

Nut bulkhead adapter 1270-06

Article no: 710252

Adapter bulkhead 1260-06-32

Article no: 710242

Position44

Aantal in tekening2

Adapter bulkhead 1260-06-32

Article no: 710242

Hose feed - EC05B Hose bracket - Rockmaster 3/8"

Article no: 740443

Position4

Aantal in tekening1

Hose feed - EC05B Hose bracket - Rockmaster 3/8"

Article no: 740443

For use with top bracket S40, Universal

Assembly stop WEO Coupling 0357490400

Article no: 712103

Position2

Aantal in tekening4

Assembly stop WEO Coupling 0357490400

Article no: 712103

Hydraulic motor EC05B, EC206, EC206B CL80cc

Article no: 720128

Position11

Aantal in tekening1

Hydraulic motor EC05B, EC206, EC206B CL80cc

Article no: 720128

Mounting plate-Deutsch-NG6

Article no: 1008340

Position34

Aantal in tekening1

Mounting plate-Deutsch-NG6

Article no: 1008340

O-ring 12,37x2,62 NBR 70 shore EC05B hydraulic pipes/motor

Article no: 710961

Position14

Aantal in tekening2

O-ring 12,37x2,62 NBR 70 shore EC05B hydraulic pipes/motor

Article no: 710961

12,37x2,62

Screw MC6S 5x30 12.9 untreated ISO4762

Article no: 610403

Position20

Aantal in tekening8

Screw MC6S 5x30 12.9 untreated ISO4762

Article no: 610403

Hose - EC05B Hose bracket- S45,S50 - Rockmaster 3/8"

Article no: 740554

Position5

Aantal in tekening1

Hose - EC05B Hose bracket- S45,S50 - Rockmaster 3/8"

Article no: 740554

For use with top bracket S45, S50

Adapter 136-06-06

Article no: 710106

Position8

Aantal in tekening2

Adapter 136-06-06

Article no: 710106

Screw MC6S 10x20 12.9 untreated ISO4762

Article no: 610451

Position43

Aantal in tekening4

Screw MC6S 10x20 12.9 untreated ISO4762

Article no: 610451

2pcs used on UNI and S45/S50 Top Brackets. 4pcs used on S40 Top Brackets

Hose bracket Top part EC05B right

Article no: 1013348

Position39

Aantal in tekening1

Hose bracket Top part EC05B right

Article no: 1013348

Hose motor - EC05B KL270 Termo 2040H

Article no: 740550

Position33

Aantal in tekening2

Hose motor - EC05B KL270 Termo 2040H

Article no: 740550

KL270 TP-04 4462-04-04

Tilt cylinder EC05B for overcenter

Article no: 1001840

Position23

Aantal in tekening1

Tilt cylinder EC05B for overcenter

Article no: 1001840

Directional valve NG6 on/off 12V Flying leads

Article no: 730166

Position26

Aantal in tekening2

Directional valve NG6 on/off 12V Flying leads

Article no: 730166

RPEB3-063Z11/01200E8V

Valve block-swivel 4v & 4-ch-EC05B

Article no: 1008197

Position24

Aantal in tekening1

Valve block-swivel 4v & 4-ch-EC05B

Article no: 1008197

Screw MC6S 5x35 12.9 untreated ISO4762

Article no: 610404

Position21

Aantal in tekening8

Screw MC6S 5x35 12.9 untreated ISO4762

Article no: 610404

Screw MF6S 8x30 10.9 untreated ISO10642

Article no: 610609

Position12

Aantal in tekening2

Screw MF6S 8x30 10.9 untreated ISO10642

Article no: 610609

10.9 Untreated DIN 7991

Screw MC6S 5x20 12.9 untreated ISO4762

Article no: 610400

Position35

Aantal in tekening2

Screw MC6S 5x20 12.9 untreated ISO4762

Article no: 610400

12.9 Untreated ISO 4762

Adapter 138-04-29 ( compact 136-04-04 )

Article no: 710135

Position9

Aantal in tekening2

Adapter 138-04-29 ( compact 136-04-04 )

Article no: 710135

Banjo bolt 4451-04

Article no: 710271

Position10

Aantal in tekening2

Banjo bolt 4451-04

Article no: 710271

Washer NL10-DPE 10,7x16,6x2,7

Article no: 611041

Position30

Aantal in tekening7

Washer NL10-DPE 10,7x16,6x2,7

Article no: 611041

Seal washer GBR06 3/8"

Article no: 710703

Position17

Aantal in tekening2

Seal washer GBR06 3/8"

Article no: 710703

Seal washer GBR04 1/4"

Article no: 710702

Position16

Aantal in tekening6

Seal washer GBR04 1/4"

Article no: 710702

Washer NL8-DPE 8,7x13,5x2,7

Article no: 611040

Position29

Aantal in tekening4

Washer NL8-DPE 8,7x13,5x2,7

Article no: 611040
