Main components 'From 2009-01'

Pos

Article

Extra Info

Quantity in drawing

Price (excl. VAT)

Rotator frame 20HD Yellow

Article no: 101277

Position4

Quantity in drawing1

€5.571,00

excl. VAT

Out of stock

Rotator frame 20HD Yellow

Article no: 101277

€5.571,00

Out of stock

Worm screw EC20

Article no: 300030

Position14

Quantity in drawing1

€2.670,00

excl. VAT

Out of stock

Worm screw EC20

Article no: 300030

€2.670,00

Out of stock

Support ring 80/100x3,5 Din 988

Article no: 650301

Position16

Quantity in drawing1

€83,50

excl. VAT

Few in stock (5)

Support ring 80/100x3,5 Din 988

Article no: 650301

€83,50

Few in stock (5)

Shim centre ring - EC20 - 0,8mm

Article no: 201405

Position44

Quantity in drawing1

€34,10

excl. VAT

Few in stock (2)

Shim centre ring - EC20 - 0,8mm

Article no: 201405

0,8 mm

€34,10

Few in stock (2)

Shim centre ring - EC20 - 1,1mm

Article no: 201407

Position46

Quantity in drawing1

€34,10

excl. VAT

Out of stock

Shim centre ring - EC20 - 1,1mm

Article no: 201407

1,1 mm

€34,10

Out of stock

Shim tilt axle - EC20 - spring steel 61x95x1

Article no: 650502

Position39

Quantity in drawing1

€11,80

excl. VAT

In stock

Shim tilt axle - EC20 - spring steel 61x95x1

Article no: 650502

1 mm

€11,80

In stock

Worm wheel EC20 M20

Article no: 300863

Position9

Quantity in drawing1

€8.209,00

excl. VAT

Out of stock

Worm wheel EC20 M20

Article no: 300863

€8.209,00

Out of stock

Shim centre ring - EC20 - 0,4mm

Article no: 202055

Position49

Quantity in drawing1

€34,10

excl. VAT

Few in stock (3)

Shim centre ring - EC20 - 0,4mm

Article no: 202055

0,4 mm

€34,10

Few in stock (3)

Shim tilt axle - EC20 - spring steel 61x95x0,5

Article no: 650501

Position38

Quantity in drawing1

€10,00

excl. VAT

In stock

Shim tilt axle - EC20 - spring steel 61x95x0,5

Article no: 650501

0,5 mm

€10,00

In stock

Screw MC6S 12x16H 12.9 ZFSHL ISO4762

Article no: 610470

Position34

Quantity in drawing2

€9,80

excl. VAT

In stock

Screw MC6S 12x16H 12.9 ZFSHL ISO4762

Article no: 610470

12.9 Untreated ISO 4762 - Changed from 05-10-03

€9,80

In stock

Shim centre ring - EC20 - 0,7mm

Article no: 201793

Position47

Quantity in drawing1

€34,10

excl. VAT

Out of stock

Shim centre ring - EC20 - 0,7mm

Article no: 201793

0,6 mm

€34,10

Out of stock

Centre ring - EC20 - should have shim, as of 05-01-01

Article no: 302807

Position7

Quantity in drawing1

€3.088,00

excl. VAT

Out of stock

Centre ring - EC20 - should have shim, as of 05-01-01

Article no: 302807

Replacing 300332 from 05-01-01 - mounted with shims

€3.088,00

Out of stock

Shim centre ring - EC20 - 0,5mm

Article no: 202056

Position50

Quantity in drawing1

€34,10

excl. VAT

Few in stock (5)

Shim centre ring - EC20 - 0,5mm

Article no: 202056

0,5 mm

€34,10

Few in stock (5)

Protective cover valve block EC20

Article no: 300118

Position5

Quantity in drawing1

€89,00

excl. VAT

Out of stock

Protective cover valve block EC20

Article no: 300118

€89,00

Out of stock

Shim centre ring - EC20 - 1,0mm

Article no: 201365

Position43

Quantity in drawing1

€46,20

excl. VAT

Out of stock

Shim centre ring - EC20 - 1,0mm

Article no: 201365

1,0 mm

€46,20

Out of stock

Shim worm screw - EC10, EC15, EC20 - 80/100x0,3

Article no: 650515

Position28

Quantity in drawing1

€4,80

excl. VAT

In stock

Shim worm screw - EC10, EC15, EC20 - 80/100x0,3

Article no: 650515

0,3 mm

€4,80

In stock

Tilt axle EC20 hardened

Article no: 302830

Position2

Quantity in drawing2

€217,60

excl. VAT

In stock

Tilt axle EC20 hardened

Article no: 302830

Replacing 300036 from 05-10-03

€217,60

In stock

Cylindrical pin CPK Ø3x12 m6

Article no: 650201

Position17

Quantity in drawing2

€1,10

excl. VAT

In stock

Cylindrical pin CPK Ø3x12 m6

Article no: 650201

€1,10

In stock

Axial washer EC10, EC20

Article no: 300031

Position13

Quantity in drawing2

€76,90

excl. VAT

Few in stock (4)

Axial washer EC10, EC20

Article no: 300031

€76,90

Few in stock (4)

Wear washer EC20

Article no: 400310

Position18

Quantity in drawing1

€412,10

excl. VAT

Out of stock

Wear washer EC20

Article no: 400310

€412,10

Out of stock

Screw M6S 10x25 8.8 FZB ISO4017

Article no: 610142

Position6

Quantity in drawing4

€1,00

excl. VAT

In stock

Screw M6S 10x25 8.8 FZB ISO4017

Article no: 610142

€1,00

In stock

O-ring 10,77x2,62 NBR 70 shore

Article no: 710910

Position19

Quantity in drawing1

€1,00

excl. VAT

In stock

O-ring 10,77x2,62 NBR 70 shore

Article no: 710910

€1,00

In stock

O-ring 419,3x5,7 Quick hitch EC20

Article no: 710909

Position24

Quantity in drawing1

€69,20

excl. VAT

Few in stock (4)

O-ring 419,3x5,7 Quick hitch EC20

Article no: 710909

€69,20

Few in stock (4)

Shim worm screw - EC10, EC15, EC20 - 80/100x0,2

Article no: 650514

Position27

Quantity in drawing1

€1,50

excl. VAT

In stock

Shim worm screw - EC10, EC15, EC20 - 80/100x0,2

Article no: 650514

0,2 mm

€1,50

In stock

Shim worm screw - EC10, EC15, EC20 - 80/100x0,1

Article no: 650513

Position26

Quantity in drawing1

€1,30

excl. VAT

Few in stock (5)

Shim worm screw - EC10, EC15, EC20 - 80/100x0,1

Article no: 650513

0,1 mm

€1,30

Few in stock (5)

Screw M6S 6x12 8.8 FZB ISO4017

Article no: 610108

Position20

Quantity in drawing8

Screw M6S 6x12 8.8 FZB ISO4017

Article no: 610108

Bushing WB802 80/85x40

Article no: 630103

Position15

Quantity in drawing1

€42,90

excl. VAT

In stock

Bushing WB802 80/85x40

Article no: 630103

€42,90

In stock

Bushing WB802 45/50x50

Article no: 630102

Position25

Quantity in drawing1

€27,50

excl. VAT

In stock

Bushing WB802 45/50x50

Article no: 630102

€27,50

In stock

Motor cover EC20(&old EC30)

Article no: 100010

Position1

Quantity in drawing1

€274,70

excl. VAT

Out of stock

Motor cover EC20(&old EC30)

Article no: 100010

€274,70

Out of stock

Feather key 10x8x50 C45 EC05B,EC15,EC20,EC214,EC219,EC226

Article no: 650102

Position21

Quantity in drawing4

€2,90

excl. VAT

In stock

Feather key 10x8x50 C45 EC05B,EC15,EC20,EC214,EC219,EC226

Article no: 650102

€2,90

In stock

Screw MC6S 16x80 12.9 untreated ISO4762

Article no: 610528

Position31

Quantity in drawing10

€8,80

excl. VAT

In stock

Screw MC6S 16x80 12.9 untreated ISO4762

Article no: 610528

€8,80

In stock

Screw M6S 10x20 8.8 FZB ISO4017

Article no: 610141

Position32

Quantity in drawing4

€1,00

excl. VAT

In stock

Screw M6S 10x20 8.8 FZB ISO4017

Article no: 610141

€1,00

In stock

Washer BRB FZB 10,5x22x2 ISO7089

Article no: 611006

Position33

Quantity in drawing8

€1,00

excl. VAT

In stock

Washer BRB FZB 10,5x22x2 ISO7089

Article no: 611006

€1,00

In stock

Bushing tilt EC20 WB802 60/65x60

Article no: 630301

Position10

Quantity in drawing2

€46,20

excl. VAT

In stock

Bushing tilt EC20 WB802 60/65x60

Article no: 630301

€46,20

In stock

Lubrication nipple 1/8 straight

Article no: 711403

Position11

Quantity in drawing14

€1,10

excl. VAT

In stock

Lubrication nipple 1/8 straight

Article no: 711403

R1/8" Straight

€1,10

In stock

O-ring 319,3x5,7 - Quick hitch EC10/EC219/EC226

Article no: 710908

Position8

Quantity in drawing1

€52,80

excl. VAT

In stock

O-ring 319,3x5,7 - Quick hitch EC10/EC219/EC226

Article no: 710908

€52,80

In stock

Cylinder axle EC20 hardened

Article no: 302853

Position36

Quantity in drawing2

€100,00

excl. VAT

In stock

Cylinder axle EC20 hardened

Article no: 302853

Replacing 300033 from 05-10-03

€100,00

In stock

Screw MC6S 8x16H 12.9 ZFSHL ISO4762

Article no: 610432

Position35

Quantity in drawing2

€1,10

excl. VAT

In stock

Screw MC6S 8x16H 12.9 ZFSHL ISO4762

Article no: 610432

12.9 Untreated ISO 4762 - Changed from 05-10-03

€1,10

In stock
