Main components

Pos

Article

Extra Info

Quantity in drawing

Price (excl. VAT)

Centre ring - EC05B, EC206

Article no: 1000773

Position19

Quantity in drawing1

£883.30

excl. VAT

Out of stock

Centre ring - EC05B, EC206

Article no: 1000773

£883.30

Out of stock

Screw MC6S 14x90 12.9 untreated ISO4762

Article no: 610510

Position21

Quantity in drawing12

£6.60

excl. VAT

Out of stock

Screw MC6S 14x90 12.9 untreated ISO4762

Article no: 610510

12.9 Untreated ISO 4762

£6.60

Out of stock

Tube unit reconstruction kit EC05B

Article no: 1011799

Position51

Quantity in drawing1

£654.80

excl. VAT

Out of stock

Tube unit reconstruction kit EC05B

Article no: 1011799

(POS. 52, 53, 54, 55, 56, 57, 58, 59 & 60 included)

£654.80

Out of stock

Valve block-swivel 4v & 4-ch-EC05B

Article no: 1008197

Position50

Quantity in drawing1

£3,133.00

excl. VAT

Out of stock

Valve block-swivel 4v & 4-ch-EC05B

Article no: 1008197

See subheading Swivels & valveblocks for exploded view

£3,133.00

Out of stock

Shim End lock EC05,EC05B,EC206 0,9mm

Article no: 1002987

Position35

Quantity in drawing1

£13.70

excl. VAT

Out of stock

Shim End lock EC05,EC05B,EC206 0,9mm

Article no: 1002987

£13.70

Out of stock

Worm screw EC05B, EC206, EC206B

Article no: 1007329

Position28

Quantity in drawing1

£997.20

excl. VAT

Out of stock

Worm screw EC05B, EC206, EC206B

Article no: 1007329

£997.20

Out of stock

End lock EC05/EC05B/EC206 outer shim

Article no: 303269

Position38

Quantity in drawing1

£198.50

excl. VAT

Out of stock

End lock EC05/EC05B/EC206 outer shim

Article no: 303269

£198.50

Out of stock

Hydraulic block(motor) - rotation EC05B

Article no: 1010409

Position53

Quantity in drawing1

£332.10

excl. VAT

Out of stock

Hydraulic block(motor) - rotation EC05B

Article no: 1010409

£332.10

Out of stock

Screw MC6S 10x20 12.9 untreated ISO4762

Article no: 610451

Position41

Quantity in drawing1

£0.80

excl. VAT

In stock

Screw MC6S 10x20 12.9 untreated ISO4762

Article no: 610451

£0.80

In stock

Screw MF6S 8x35 10.9 untreated ISO10642

Article no: 610611

Position58

Quantity in drawing2

£0.80

excl. VAT

Out of stock

Screw MF6S 8x35 10.9 untreated ISO10642

Article no: 610611

£0.80

Out of stock

Shim kit centre ring - EC05B/EC206

Article no: 1027074

Position5

Quantity in drawing1

£156.20

excl. VAT

Out of stock

Shim kit centre ring - EC05B/EC206

Article no: 1027074

(POS. 6, 7, 8, 9, 10 & 11 included)

£156.20

Out of stock

Screw MC6S 6x70 12.9 untreated ISO4762

Article no: 610496

Position20

Quantity in drawing2

£1.10

excl. VAT

Out of stock

Screw MC6S 6x70 12.9 untreated ISO4762

Article no: 610496

12.9 Untreated ISO 4762

£1.10

Out of stock

Lubrication nipple M8x1 straight

Article no: 711408

Position2

Quantity in drawing3

£0.80

excl. VAT

Out of stock

Lubrication nipple M8x1 straight

Article no: 711408

£0.80

Out of stock

Motor cover EC05B

Article no: 1008792

Position61

Quantity in drawing1

£301.00

excl. VAT

Out of stock

Motor cover EC05B

Article no: 1008792

£301.00

Out of stock

Shim centre ring - EC05B/EC206 - 0,9mm

Article no: 1009603

Position10

Quantity in drawing1

£17.80

excl. VAT

Out of stock

Shim centre ring - EC05B/EC206 - 0,9mm

Article no: 1009603

£17.80

Out of stock

Shim End lock EC05,EC05B,EC206 1,0mm

Article no: 1008540

Position36

Quantity in drawing1

£21.60

excl. VAT

Out of stock

Shim End lock EC05,EC05B,EC206 1,0mm

Article no: 1008540

£21.60

Out of stock

Hydraulic block(valve block) - rotation EC05B

Article no: 1010405

Position59

Quantity in drawing1

£176.90

excl. VAT

Out of stock

Hydraulic block(valve block) - rotation EC05B

Article no: 1010405

£176.90

Out of stock

Assembly stop WEO Coupling 0357490400

Article no: 712103

Position56

Quantity in drawing4

£2.90

excl. VAT

Out of stock

Assembly stop WEO Coupling 0357490400

Article no: 712103

£2.90

Out of stock

Shim End lock EC05,EC05B,EC206 0,6mm

Article no: 405677

Position32

Quantity in drawing1

£6.00

excl. VAT

Out of stock

Shim End lock EC05,EC05B,EC206 0,6mm

Article no: 405677

£6.00

Out of stock

Screw cover M10

Article no: 611305

Position43

Quantity in drawing6

£0.80

excl. VAT

In stock

Screw cover M10

Article no: 611305

£0.80

In stock

Shim centre ring - EC05B/EC206 - 1mm

Article no: 1009604

Position11

Quantity in drawing1

£34.80

excl. VAT

Few in stock (5)

Shim centre ring - EC05B/EC206 - 1mm

Article no: 1009604

£34.80

Few in stock (5)

Shim End lock EC05,EC05B,EC206 0,5mm

Article no: 405125

Position31

Quantity in drawing1

£10.10

excl. VAT

In stock

Shim End lock EC05,EC05B,EC206 0,5mm

Article no: 405125

£10.10

In stock

Cylinder axle EC05, EC10, EC15 hardened

Article no: 404276

Position66

Quantity in drawing1

£78.10

excl. VAT

Few in stock (4)

Cylinder axle EC05, EC10, EC15 hardened

Article no: 404276

£78.10

Few in stock (4)

Shim centre ring - EC05B/EC206 - 0,6mm

Article no: 1009602

Position7

Quantity in drawing1

£17.70

excl. VAT

In stock

Shim centre ring - EC05B/EC206 - 0,6mm

Article no: 1009602

£17.70

In stock

Shim End lock EC05,EC05B,EC206 0,4mm

Article no: 405124

Position30

Quantity in drawing1

£10.60

excl. VAT

In stock

Shim End lock EC05,EC05B,EC206 0,4mm

Article no: 405124

£10.60

In stock

Support ring 60/75 x3 ss

Article no: 650303

Position26

Quantity in drawing1

£13.60

excl. VAT

Out of stock

Support ring 60/75 x3 ss

Article no: 650303

£13.60

Out of stock

Shim centre ring - EC05B/EC206 - 0,7mm

Article no: 1001664

Position8

Quantity in drawing1

£21.60

excl. VAT

In stock

Shim centre ring - EC05B/EC206 - 0,7mm

Article no: 1001664

£21.60

In stock

Shim tilt axle - EC05B - 60x41x0.5

Article no: 1010819

Position63

Quantity in drawing2

£8.20

excl. VAT

Out of stock

Shim tilt axle - EC05B - 60x41x0.5

Article no: 1010819

Used if required

£8.20

Out of stock

Worm wheel EC05B, EC206

Article no: 1000751

Position12

Quantity in drawing1

£2,775.00

excl. VAT

Out of stock

Worm wheel EC05B, EC206

Article no: 1000751

£2,775.00

Out of stock

Screw cover M12

Article no: 611301

Position49

Quantity in drawing2

£0.80

excl. VAT

In stock

Screw cover M12

Article no: 611301

£0.80

In stock

Hydraulic motor EC05B, EC206, EC206B CL80cc

Article no: 720128

Position46

Quantity in drawing1

£940.70

excl. VAT

Few in stock (2)

Hydraulic motor EC05B, EC206, EC206B CL80cc

Article no: 720128

£940.70

Few in stock (2)

Tilt axle EC05 hardened

Article no: 404376

Position65

Quantity in drawing2

£138.30

excl. VAT

Few in stock (4)

Tilt axle EC05 hardened

Article no: 404376

£138.30

Few in stock (4)

Shim kit End lock - EC05/EC05B/EC206

Article no: 1006356

Position29

Quantity in drawing1

£145.80

excl. VAT

In stock

Shim kit End lock - EC05/EC05B/EC206

Article no: 1006356

(POS. 30, 31, 32, 33, 34, 35, 36 & 37 included)

£145.80

In stock

Wiper seal Quick hitch EC05B, EC206

Article no: 710957

Position14

Quantity in drawing1

£90.30

excl. VAT

Few in stock (1)

Wiper seal Quick hitch EC05B, EC206

Article no: 710957

£90.30

Few in stock (1)

Screw MF6S 4x10 10.9 untreated ISO10642

Article no: 610605

Position4

Quantity in drawing4

£0.80

excl. VAT

In stock

Screw MF6S 4x10 10.9 untreated ISO10642

Article no: 610605

£0.80

In stock

Shim centre ring - EC05B/EC206 - 0,8mm

Article no: 1001666

Position9

Quantity in drawing1

£18.80

excl. VAT

Out of stock

Shim centre ring - EC05B/EC206 - 0,8mm

Article no: 1001666

£18.80

Out of stock

Wear washer EC05B, EC206

Article no: 1000774

Position3

Quantity in drawing1

£280.30

excl. VAT

Few in stock (1)

Wear washer EC05B, EC206

Article no: 1000774

£280.30

Few in stock (1)

Axial washer EC05

Article no: 400394

Position27

Quantity in drawing2

£39.50

excl. VAT

Few in stock (3)

Axial washer EC05

Article no: 400394

£39.50

Few in stock (3)

Shim centre ring - EC05B/EC206 - 0,5mm

Article no: 1001665

Position6

Quantity in drawing1

£19.80

excl. VAT

Few in stock (5)

Shim centre ring - EC05B/EC206 - 0,5mm

Article no: 1001665

£19.80

Few in stock (5)

Cylindrical pin CPK Ø3x12 m6

Article no: 650201

Position24

Quantity in drawing2

£0.90

excl. VAT

In stock

Cylindrical pin CPK Ø3x12 m6

Article no: 650201

£0.90

In stock

Wiper seal Quick hitch EC02, centre ring EC05B, EC206

Article no: 710952

Position18

Quantity in drawing1

£54.60

excl. VAT

Few in stock (5)

Wiper seal Quick hitch EC02, centre ring EC05B, EC206

Article no: 710952

£54.60

Few in stock (5)

Guide belt centre ring EC05B,EC206

Article no: 710958

Position17

Quantity in drawing1

£53.60

excl. VAT

Few in stock (1)

Guide belt centre ring EC05B,EC206

Article no: 710958

£53.60

Few in stock (1)

Shim tilt axle - EC05B - 60x41x1,0

Article no: 1010820

Position64

Quantity in drawing2

£8.20

excl. VAT

Out of stock

Shim tilt axle - EC05B - 60x41x1,0

Article no: 1010820

Used if required

£8.20

Out of stock

Bushing tilt EC05 WB802 40/44x30

Article no: 630307

Position69

Quantity in drawing2

£13.60

excl. VAT

In stock

Bushing tilt EC05 WB802 40/44x30

Article no: 630307

Part of top part assembly

£13.60

In stock

Plug VSTIR18ED 1/8"

Article no: 711503

Position39

Quantity in drawing2

£5.30

excl. VAT

In stock

Plug VSTIR18ED 1/8"

Article no: 711503

£5.30

In stock

Wear ring EC05B, EC206

Article no: 1000772

Position16

Quantity in drawing1

£187.20

excl. VAT

Few in stock (1)

Wear ring EC05B, EC206

Article no: 1000772

£187.20

Few in stock (1)

Bushing WB802 60/65x30

Article no: 630305

Position25

Quantity in drawing1

£27.30

excl. VAT

Out of stock

Bushing WB802 60/65x30

Article no: 630305

£27.30

Out of stock

Bushing WB802 35/39x30

Article no: 630315

Position45

Quantity in drawing1

£16.90

excl. VAT

Out of stock

Bushing WB802 35/39x30

Article no: 630315

£16.90

Out of stock

Hose motor - EC05B KL270 Termo 2040H

Article no: 740550

Position57

Quantity in drawing2

£51.70

excl. VAT

Out of stock

Hose motor - EC05B KL270 Termo 2040H

Article no: 740550

£51.70

Out of stock

Screw MC6S 8x16H 12.9 ZFSHL ISO4762

Article no: 610432

Position67

Quantity in drawing3

£0.90

excl. VAT

In stock

Screw MC6S 8x16H 12.9 ZFSHL ISO4762

Article no: 610432

12.9 Dacromet ISO 4762

£0.90

In stock

O-ring 12,37x2,62 NBR 70 shore EC05B hydraulic pipes/motor

Article no: 710961

Position52

Quantity in drawing2

£0.80

excl. VAT

Few in stock (2)

O-ring 12,37x2,62 NBR 70 shore EC05B hydraulic pipes/motor

Article no: 710961

£0.80

Few in stock (2)

Screw M6S 8x14 8.8 FZB ISO4017

Article no: 610188

Position62

Quantity in drawing7

£0.80

excl. VAT

Out of stock

Screw M6S 8x14 8.8 FZB ISO4017

Article no: 610188

£0.80

Out of stock

Washer NL12-DPE 13,0x19,5x2,7

Article no: 611042

Position47

Quantity in drawing2

£3.10

excl. VAT

In stock

Washer NL12-DPE 13,0x19,5x2,7

Article no: 611042

£3.10

In stock

Lubrication nipple 1/8 straight

Article no: 711403

Position44

Quantity in drawing4

£0.90

excl. VAT

In stock

Lubrication nipple 1/8 straight

Article no: 711403

£0.90

In stock

Slotted pin 5x20 S5 Brass

Article no: 640407

Position15

Quantity in drawing4

£1.30

excl. VAT

Few in stock (4)

Slotted pin 5x20 S5 Brass

Article no: 640407

£1.30

Few in stock (4)

Washer NL10-DPE 10,7x16,6x2,7

Article no: 611041

Position40

Quantity in drawing4

£1.90

excl. VAT

In stock

Washer NL10-DPE 10,7x16,6x2,7

Article no: 611041

£1.90

In stock

Feather key 10x8x50 C45 EC05B,EC15,EC20,EC214,EC219,EC226

Article no: 650102

Position13

Quantity in drawing6

£2.40

excl. VAT

In stock

Feather key 10x8x50 C45 EC05B,EC15,EC20,EC214,EC219,EC226

Article no: 650102

£2.40

In stock

Washer NL8-DPE 8,7x13,5x2,7

Article no: 611040

Position54

Quantity in drawing11

£1.80

excl. VAT

In stock

Washer NL8-DPE 8,7x13,5x2,7

Article no: 611040

£1.80

In stock

O-ring 9,25x1,78 FKM 90 shore Viton Green NG6

Article no: 710901

Position60

Quantity in drawing2

£0.80

excl. VAT

In stock

O-ring 9,25x1,78 FKM 90 shore Viton Green NG6

Article no: 710901

£0.80

In stock
